BOE ZV080WUM-A40 LCD

Specification

Model P/N:ZV080WUM-A40
Brand:BOE
Diagonal Size:8.0"
Resolution:1200(RGB)×1920, WUXGA 283PPI
Contrast Ratio:1200:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, Assembly
Pixel Format:RGB Vertical Stripe
Active Area:107.64(W)×172.224(H) mm
Bezel Opening:-
Outline Dim:135(H)×199.82(V) ×2.8(D) mm
Treatment:Anti Fingerprint, Hard coating
Luminance:350 cd/m² (Typ.)
View Direction:Symmetry
Response Time:35 (Typ.)(Tr+Td)
Operating Mode:-
Support Color:16.7M 71% NTSC
Light Source:WLED [8S3P] , W/O Driver
Weight:130±10g
Designed For:Industrial
Frame Rate:60Hz
Touch Panel:PCAP, I²C
Interface Type:MIPI (4 data lanes) , 40 pins Connector
Power Supply:3.3V (Typ.)
