CMO M156B1-P01 LCD

Specification

Model P/N:M156B1-P01
Brand:CMO
Diagonal Size:15.6"
Resolution:1366(RGB)×768, WXGA 100PPI
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:45/45/20/45 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , FOB
Pixel Format:RGB Vertical Stripe
Active Area:344.232(W)×193.536(H) mm
Bezel Opening:-
Outline Dim:353.632(H)×203.068(V) ×1.83(D) mm
Treatment:Antiglare (Haze 25%), Hard coating (3H)
Luminance:0 cd/m²
View Direction:6 o'clock
Response Time:2/6 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:16.7M 66% NTSC
Light Source:No B/L
Weight:315g (Max.)
Designed For:Desktop Monitor
Frame Rate:75Hz
Touch Panel:Without
Interface Type:LVDS (1 ch, 8-bit) , 30 pins Connector
Power Supply:5.0V (Typ.)
Plate Thickness:0.70+0.70 mm
Transmittance:11.0% (Typ.)(with Polarizer)
D-IC Detail:Built-in 6 source COF + 3 gate COG chips
