CMO M150X4-L06 LCD

Specification

Model P/N:M150X4-L06
Brand:CMO
Diagonal Size:15.0"
Resolution:1024(RGB)×768, XGA 85PPI
Brightness:200 cd/m² (Typ.)
Contrast Ratio:350:1 (Typ.) (TM)
Viewing Angle:60/60/40/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:304.128(W)×228.096(H) mm
Bezel Opening:307.5(W)×231.4(H) mm
Response Time:6/17 (Typ.)(Tr/Td)
Outline Size:321(W)×245.4(H) ×10(D) mm
Surface:-
Best View on:6 o'clock
Display Colors:16.2M
Lamp Type:2 pcs CCFL , 50K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:930g (Max.)
Application:Desktop Monitor
Signal Interface:LVDS (1 ch, 8-bit) , 20 pins Connector
Input Voltage:3.3V (Typ.)
