CMO M170E1-01 LCD

Specification

Model P/N:M170E1-01
Brand:CMO
Diagonal Size:17.0"
Resolution:1280(RGB)×1024, SXGA 96PPI
Contrast Ratio:300 : 1 (Typ.) (TM)
Viewing Angle:60/60/40/60 (Typ.)(CR≥10)
Color Depth:16.2M 63% NTSC
Backlight:4 pcs CCFL , 50K hours , No Driver
Signal Type:LVDS (2 ch, 8-bit) , Connector 30 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:337.92(W)×270.336(H) mm
Bezel Opening:342.0(W)×274.4(H) mm
Treatment:Antiglare (Haze 25%), Hard coating
Luminance:230 cd/m² (Typ.)
Response:15/35 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:2.00/2.15Kgs (Typ./Max.)
Used for:Desktop Monitor
Refresh Rate:75Hz
Touchscreen:Without
Voltage Supply:5.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):404×322.2×21 (H×V×D)
