LQ035NC211 Innolux LCD panel replacement

Panel Brand：ChiHsin
Panel Model：LQ035NC211
Panel Size：3.5 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：320(RGB)×240 , QVGA
Pixel Format：RGB Vertical Stripe
Display Area：70.08(W)×52.56(H) mm
Bezel Opening：72.00(W)×54.56(H) mm
Outline Size：76.9(W)×63.9(H)×4.56(D) mm
Surface：Antiglare (Haze 20%)
Brightness：200 cd/m2 (Typ.)
Contrast Ratio：400:1 (Typ.) (TM)
Viewing Angle：60/60/50/55 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：6 o’clock
Response Time：10/15 (Typ.)(Tr/Td)
Display Colors：16.7M 60%(CIE1931)
Lamp Type：6S1PWLED, 50K hours, Without Driver
Frequency：-
Touch Screen：Embeded (4-wire Resistive)
Panel Weight： 40.0g (Typ.)
Application： Digital Still Camera, Digital Video Camera, Portable Navigation,
Signal Interface： Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins, FPC
Input Voltage：3.3V (Typ.)(VCC)
Environment：Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C
