NL6448BC33-64D NLT LCD panel replacement for Industrial Application

Manufacturer：NEC
Model Name：NL6448BC33-64D
Screen Size：10.4 inch
Screen Type：LCM,a-Si TFT-LCD
Pixel Number：640(RGB)×480 (VGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)：211.2 × 158.4 (H×V)
Outline(mm)： 243 × 185.1× 11 (H×V×D)
Bezel Area(mm)：215.4 × 161.8 (H×V)
Treatment：Antiglare, Hard coating (3H)
Luminance：450 cd/m2 (Typ.)
Contrast Ratio：600 : 1 (Typ.) (TM)
Viewing Angle：80/80/80/55 (Typ.)(CR≥10)
Response：6/25 (Typ.)(Tr/Td) ms
Good View at：6 o'clock
Work Mode：TN, Normally White, Transmissive
Color Depth：262K 40%(CIE1931)
Backlight：2 pcsCCFL, 50K hours, No Driver
Mass： 475/500g (Typ./Max.)
Used for： Industrial Application,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type： CMOS (1 ch, 6-bit), Connector , 31 pins
Voltage Supply：3.3/5.0V (Typ.)
Max. Ratings：： Storage Temp.: -30 ~ 80 °COperating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s2)
