NL6448BC33-71C NLT LCD panel replacement for Industrial Application

Brand：NEC
Model：NL6448BC33-71C
Diagonal Size：10.4 inch
Type：a-Si TFT-LCD , LCM
Pixel Format：640(RGB)×480[VGA]
Configuration：RGB Vertical Stripe
Active Area：211.2(H)×158.4(V) mm
Outline Dim.：243(H)×185.1(V)×11(D) mm
Bezel Area：215.4(H)×161.8(V) mm
Treatment：Clear, Hard coating (2H), Antireflection
Luminance：900 cd/m2 (Typ.)
Contrast Ratio：900:1 (Typ.) (TM)
View Direction：-
Response Time：3/15 (Typ.)(Tr/Td)
Viewing Angle：80/80/80/80 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K/16.7M 40%(CIE1931)
Light Source：WLED[4 strings], 70K hours, W/O Driver
Weight： 475/500g (Typ./Max.)
Designed For： Industrial Application,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 20 pinsLVDS (1 ch, 6/8-bit), Connector
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s2)
