Univision UG-2832ASYCG01 LCD

Specification

Model P/N:UG-2832ASYCG01
Brand:Univision
Diagonal Size:2.2"
Resolution:128×32 59PPI
Contrast Ratio:2000:1 (Min.) (TM)
Viewing Angle:80/80/80/80 (Min.)
Panel Type:PM-OLED, OLED
Pixel Format:Rectangle
Active Area:55.02(W)×13.1(H) mm
Bezel Opening:57.02(W)×15.1(H) mm
Outline Dim:62(H)×24(V) ×2.1(D) mm
Treatment:-
Luminance:120 cd/m² (Typ.)
View Direction:Symmetry
Response Time:-
Operating Mode:-
Support Color:Mono(Yellow)
Light Source:self , 40K hours
Weight:5.80g
Designed For:Handheld & PDA ，Instruments & Meters
Frame Rate:-
Touch Panel:Without
Interface Type:8-bit 6800/8080 parallel, 4-wire SPI, I²C , 24 pins FPC
Power Supply:2.8/12.5V (Typ.)(VDD/VCC)
D-IC Detail:COG Built-in SSD1305
