HITACHI TX20D28VM2BPA LCD

Specification

Model P/N:TX20D28VM2BPA
Brand:HITACHI
Diagonal Size:8.0"
Resolution:800(RGB)×480, WVGA 116PPI
Brightness:320 cd/m² (Typ.)
Contrast Ratio:600:1 (Typ.) (TM)
Viewing Angle:80/80/60/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:174(W)×104.4(H) mm
Bezel Opening:178.0(W)×108.4(H) mm
Response Time:20/10 (Typ.)(Tr/Td)
Outline Size:189(W)×120(H) ×9.5(D) mm
Surface:Antiglare
Best View on:6 o'clock
Display Colors:262K 60% NTSC
Lamp Type:3S15P WLED , 40K hours , With LED Driver
Frequency:60Hz
Touch Screen:4-wire Resistive Touch, F/G
Panel Weight:240g (Typ.)
Application:Industrial
Signal Interface:LVDS (1 ch, 6-bit) , 20 pins Connector
Input Voltage:3.3V (Typ.)
