HITACHI TX20D208VM0BAB LCD

Specification

Model P/N:TX20D208VM0BAB
Brand:HITACHI
Diagonal Size:8.0"
Resolution:800(RGB)×480, WVGA 116PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M 70% NTSC
Backlight:2 strings WLED , 100K hours , No Driver
Signal Type:LVDS (1 ch, 8-bit) , Connector 20 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:174(W)×104.4(H) mm
Bezel Opening:177.4(W)×107.8(H) mm
Treatment:-
Luminance:1200 cd/m² (Typ.)
Response:30 (Max.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:IPS, Normally Black, Transmissive
Mass:275g (Typ.)
Used for:Industrial ，Rugged Industry ，Outdoor High Brightness ，Automotive Display
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²)
Outline (mm):190.8×120.5×16.2 (H×V×D)
