TM060SDH01 Tianma LCD panel replacement

Brand：TIANMA
Model：TM060SDH01
Diagonal Size：6.0 inch
Type：EPD, EPD
Pixel Format：800×600[SVGA]
Configuration：Rectangle
Active Area：122.4(H)×90.6(V) mm
Outline Dim.：137.9(H)×104.1(V) mm
Bezel Area：-
Treatment：Antiglare, Hard coating
Luminance：-
Contrast Ratio：8:1 (Typ.) (RF)
View Direction：-
Response Time：540 (Typ.)(Tr+Td)
Viewing Angle：-
Operating Mode：-
Support Color：Grayscale
Light Source：No B/L
Weight： 35.0±5.0g
Designed For： E-Book Reader,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 39 pinsParallel Data (8-bit), FPC
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -10 ~ 60 °C
