LQ231U1LW21 SHARP LCD panel replacement

Brand：SHARP
Model：LQ231U1LW21
Diagonal Size：23.1 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：1600(RGB)×1200[UXGA]
Configuration： RGB Vertical Stripe
Active Area：470.4(H)×352.8(V) mm
Outline Dim.：530(H)×432.8(V) mm
Luminance：250 cd/m2 (Typ.)
Contrast Ratio： –
View Direction：-
Response Time：-
Viewing Angle：85/85/85/85 (Min.)(CR≥10)
Operating Mode：Transmissive
Support Color：16.7M
Light Source：CCFL[6 pcs], With Inverter
Weight： 5.50Kgs (Max.)
Designed For： Industrial Application,
Interface Type： OpenLDI
Environment： Operating Temperature: 0 ~ 45 °C ; Storage Temperature: -20 ~ 60 °C
