BOE NV150FHB-N31 LCD

Specification

Model P/N:NV150FHB-N31
Brand:BOE
Diagonal Size:15.0"
Resolution:1920(RGB)×1080, FHD 146PPI
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , FOB
Pixel Format:RGB Vertical Stripe
Active Area:332.064(W)×186.786(H) mm
Bezel Opening:-
Outline Dim:337.26(H)×197.206(V) ×0.64(D) mm
Treatment:Antiglare
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:30 (Typ.)(Tr+Td)
Operating Mode:HADS, Normally Black, Transmissive
Support Color:262K 100% sRGB
Light Source:No B/L
Designed For:Laptop
Frame Rate:60Hz
Touch Panel:Without
Interface Type:eDP (2 Lanes) , eDP1.4b , 30 pins Connector
Form Style:-
Plate Thickness:0.20+0.20 mm
Transmittance:6.2% (Typ.)
D-IC Detail:COG Built-in 4 source chips
