E Ink PM101ZM1 LCD

Specification

Model P/N:PM101ZM1
Brand:E Ink
Diagonal Size:10.0"
Resolution:1024(RGB)×576, WSVGA 117PPI
Contrast Ratio:400:1 (Typ.) (TM)
Viewing Angle:45/45/15/35 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:221.184(W)×124.416(H) mm
Bezel Opening:226.34(W)×128.1(H) mm
Outline Dim:235(H)×143(V) ×5.2(D) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:200 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:8 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 48% NTSC
Light Source:WLED [3S10P] , 20K hours , With LED Driver
Weight:250g (Max.)
Designed For:Digital Photo Frame ，Portable DVD Player
Frame Rate:60Hz
Touch Panel:Without
Interface Type:LVDS (1 ch, 6-bit) , 40 pins Connector
Power Supply:3.3V (Typ.)
