E Ink PD080SL6 LCD

Specification

Model P/N:PD080SL6
Brand:E Ink
Diagonal Size:8.0"
Resolution:800(RGB)×600, SVGA 125PPI
Brightness:1400 cd/m² (Typ.)
Contrast Ratio:700:1 (Typ.) (TM)
Viewing Angle:75/75/55/65 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:162(W)×121.5(H) mm
Bezel Opening:164.4(W)×124.0(H) mm
Response Time:15/25 (Typ.)(Tr/Td)
Outline Size:200(W)×152(H) ×17.77(D) mm
Surface:Antiglare
Best View on:6 o'clock
Display Colors:262K
Lamp Type:9S1P WLED , 50K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:392±15g
Application:Industrial ，Outdoor High Brightness
Signal Interface:LVDS (1 ch, 6-bit) , 20 pins Connector
Input Voltage:3.3V (Typ.)
