AMPIRE AM-800480AFTMQW-00H LCD

Specification

Model P/N:AM-800480AFTMQW-00H
Brand:AMPIRE
Diagonal Size:7.0"
Resolution:800(RGB)×480, WVGA 134PPI
Contrast Ratio:500 : 1 (Typ.) (TM)
Viewing Angle:70/70/50/70 (Typ.)(CR≥10)
Color Depth:16.7M
Backlight:WLED , 2K hours , No Driver
Signal Type:Parallel RGB (1 ch, 8-bit) , 50 pins FPC
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:154.08(W)×85.92(H) mm
Bezel Opening:-
Treatment:-
Luminance:250 cd/m² (Typ.)
Outline(mm):164.9 × 100 × 5.3 (H×V×D)
Response:10/15 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:-
Used for:Industrial
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3/10.4/16/-7V (Typ.)(DVDD/AVDD/VGH/VGL)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
