BOE HT156WXB-500 LCD

Specification

Model P/N:HT156WXB-500
Brand:BOE
Diagonal Size:15.6"
Resolution:1366(RGB)×768, WXGA 100PPI
Brightness:220 cd/m² (Typ.)
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:45/45/15/35 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:344.232(W)×193.536(H) mm
Bezel Opening:-
Response Time:8 (Typ.)(Tr+Td)
Outline Size:359.3(W)×209.5(H) ×5.5(D) mm
Surface:-
Best View on:-
Display Colors:262K
Lamp Type:WLED , With LED Driver
Frequency:60Hz
Touch Screen:Without
Application:Laptop
Signal Interface:LVDS (1 ch, 6-bit) , 40 pins Connector
Input Voltage:3.3V (Typ.)
Shape Style:Wedge (PCBA Bent, T≥5.2mm)
