BOE HT170E02-100 LCD

Specification

Model P/N:HT170E02-100
Brand:BOE
Diagonal Size:17.0"
Resolution:1280(RGB)×1024, SXGA 96PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Color Depth:16.2M 72% NTSC
Backlight:2 pcs CCFL , 50K hours , No Driver
Signal Type:LVDS (2 ch, 8-bit) , Connector 30 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:337.92(W)×270.336(H) mm
Bezel Opening:341.5(W)×273.9(H) mm
Treatment:Antiglare (Haze 25%), Hard coating (3H)
Luminance:250 cd/m² (Typ.)
Response:1.5/3.5 (Typ.)(Tr/Td) ms
Good View at:-
Work Mode:TN, Normally White, Transmissive
Mass:1.65Kgs (Typ.)
Used for:Desktop Monitor
Refresh Rate:75Hz
Touchscreen:Without
Voltage Supply:5.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):358.5×296.5×13.5 (H×V×D)
