BOE ZV070WSM-A10 LCD

Specification

Model P/N:ZV070WSM-A10
Brand:BOE
Diagonal Size:7.0"
Resolution:1024(RGB)×600, WSVGA 170PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M 50% NTSC
Backlight:4S6P WLED , 20K hours , No Driver
Signal Type:LVDS (1 ch, 8-bit) , 40 pins FPC
Panel Type:a-Si TFT-LCD, Assembly
Pixel Format:RGB Vertical Stripe
Active Area:154.214(W)×85.92(H) mm
Bezel Opening:-
Treatment:-
Luminance:250 cd/m² (Typ.)
Outline(mm):216 × 120.45 × 4.97 (H×V×D)
Response:30 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:-
Mass:TBD
Used for:Industrial
Refresh Rate:60Hz
Touchscreen:PCAP
Voltage Supply:3.3/9.6/18/-6V (Typ.)(VDD/AVDD/VGH/VGL)
Max Ratings:Storage Temp.: -30 ~ 70 °C Operating Temp.: -20 ~ 60 °C
