Univision UG-2828GDEDF15 LCD

Specification

Model P/N:UG-2828GDEDF15
Brand:Univision
Diagonal Size:1.5"
Resolution:128(RGB)×128 121PPI
Contrast Ratio:2000 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Min.)
Color Depth:262K
Backlight:self , 20K hours
Signal Type:8-bit 6800/8080 parallel, 3/4-wire SPI , FPC 30 pins
Panel Type:PM-OLED, OLED
Pixel Format:RGB Vertical Stripe
Active Area:26.855(W)×26.864(H) mm
Bezel Opening:28.855(W)×28.864(H) mm
Treatment:-
Luminance:90 cd/m² (Typ.)
Response:-
Good View at:Symmetry
Work Mode:-
Mass:3.80g (Typ.)
Used for:Mobile Phone ，Handheld & PDA ，Square Display
Refresh Rate:-
Touchscreen:Without
Voltage Supply:2.8/2.5/1.8/13V (Typ.)(VCI/VDD/VDDIO/VCC)
Max Ratings:Storage Temp.: -40 ~ 80 °C Operating Temp.: -30 ~ 70 °C
Outline (mm):33.8×34×1.7 (H×V×D)
Driver IC list:Built-in COF SSD1351
