AUO T260XVN01.0 LCD

Specification

Model P/N:T260XVN01.0
Brand:AUO
Diagonal Size:26.0"
Resolution:1366(RGB)×768, WXGA 60PPI
Contrast Ratio:3000:1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:575.769(W)×323.712(H) mm
Bezel Opening:580.2(W)×328.2(H) mm
Outline Dim:609.8(H)×357.8(V) mm
Treatment:Antiglare (Haze 2%), Hard coating (3H)
Luminance:300 cd/m² (Typ.)
View Direction:Symmetry
Response Time:6.5 (Typ.)(G to G)
Operating Mode:AMVA3, Normally Black, Transmissive
Support Color:16.7M 68% NTSC
Light Source:WLED , 30K hours , W/O Driver
Weight:3.10Kgs (Typ.)
Designed For:TV Sets
Frame Rate:60Hz
Touch Panel:Without
Interface Type:LVDS (1 ch, 8-bit) , 30 pins Connector
Power Supply:12.0V (Typ.)
