BOE TS110QDM-LP0 LCD

Specification

Model P/N:TS110QDM-LP0
Brand:BOE
Diagonal Size:11.0"
Resolution:1600(RGB)×2560, WQXGA 275PPI
Contrast Ratio:1500 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M 98% DCI-P3
Backlight:8S5P WLED , 15K hours , No Driver
Signal Type:MIPI C-phy (2 ch, 3 data lanes) , 78 pins Connector
Panel Type:LTPS TFT-LCD, Assembly
Pixel Format:RGB Vertical Stripe
Active Area:147.408(W)×235.853(H) mm
Bezel Opening:-
Treatment:Hard coating (3H)
Luminance:480 cd/m² (Typ.)
Outline(mm):161.388 × 249.833 × 4.61 (H×V×D)
Response:16 (Typ.)(Tr+Td), 20 (Typ.)(G to G) ms
Good View at:Symmetry
Work Mode:-
Mass:175W (Max.)
Used for:Pad & Tablet
Refresh Rate:120Hz
Touchscreen:In-Cell Touch, I²C/SPI
Voltage Supply:1.8/5.8/-5.8V (Typ.)(IOVCC/VSP/VSN)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
