TIANMA TM024HDH13 LCD

Specification

Model P/N:TM024HDH13 1
Brand:TIANMA
Diagonal Size:2.4"
Resolution:240(RGB)×320, QVGA 166PPI
Contrast Ratio:350:1 (Typ.) (TM)
Viewing Angle:45/45/40/20 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:36.72(W)×48.96(H) mm
Bezel Opening:-
Outline Dim:42.72(H)×59.46(V) ×3(D) mm
Treatment:Clear, Hard coating (3H)
Luminance:210 cd/m² (Typ.)
View Direction:12 o'clock
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 60% NTSC
Light Source:WLED [4S1P] , 20K hours , W/O Driver
Weight:10.1g (Typ.)
Designed For:Mobile Phone
Frame Rate:60Hz
Touch Panel:Without
Interface Type:CPU/RGB , 36 pins FPC
Power Supply:2.8V (Typ.)
