Sharp LQ10D363 LCD

Specification

Model P/N:LQ10D363
Brand:Sharp
Diagonal Size:10.4"
Resolution:640(RGB)×480, VGA 76PPI
Viewing Angle:-
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:211.2(W)×158.4(H) mm
Bezel Opening:216.2(W)×163.4(H) mm
Outline Dim:246.5(H)×179.4(V) mm
Treatment:Antiglare (Haze 28%), Hard coating (3H), Antireflection
View Direction:-
Response Time:-
Operating Mode:TN, Normally White, Transmissive
Support Color:262K
Light Source:CCFL [1 pcs] , 25K hours , W/O Driver
Weight:-
Designed For:Industrial
Frame Rate:-
Touch Panel:Without
Power Supply:5.0V (Typ.)(VCC)
