HITACHI SX25S003-ZZA LCD

Specification

Model P/N:SX25S003-ZZA
Brand:HITACHI
Diagonal Size:10.0"
Resolution:800(RGB)×600, SVGA 100PPI
Contrast Ratio:50:1 (Typ.) (TM)
Viewing Angle:40 (Typ.)(CR≥2, Φ2-Φ1)
Panel Type:CSTN-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:202.8(W)×152.1(H) mm
Bezel Opening:207.0(W)×156.0(H) mm
Outline Dim:236(H)×168(V) ×7.9(D) mm
Treatment:-
Luminance:160 cd/m² (Typ.)
View Direction:12 o'clock
Response Time:170/130 (Typ.)(Tr/Td)
Operating Mode:STN, Normally Black, Transmissive
Support Color:Color 36% NTSC
Light Source:CCFL [2 pcs] , W/O Driver
Weight:442g (Typ.)
Designed For:Industrial
Frame Rate:120Hz
Touch Panel:4-wire Resistive Touch
Interface Type:Parallel Data (1ch, 8-bit) , 40 pins Connector
Power Supply:3.3V (Typ.)
