BOE COG-VLUK7029-204 LCD

Specification

Model P/N:COG-VLUK7029-204
Brand:BOE
Diagonal Size:4.0"
Resolution:240(RGB)×320, QVGA 99PPI
Brightness:450 cd/m² (Typ.)
Contrast Ratio:400:1 (Min.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:61.2(W)×81.6(H) mm
Bezel Opening:64.0(W)×84.4(H) mm
Response Time:40 (Typ.)(Tr+Td)
Outline Size:78.2(W)×102.7(H) ×9.6(D) mm
Surface:Antiglare
Best View on:Symmetry
Display Colors:262K 67% NTSC
Lamp Type:4S1P WLED , 30K hours , Without Driver
Frequency:65Hz
Touch Screen:Without
Panel Weight:0.11Kgs
Application:Automotive Display
Signal Interface:Parallel RGB (1 ch, 6-bit) + SPI , 50 pins FPC
Input Voltage:3.3/3.3V (Typ.)(VCC/VCI)
