PVI PA050XSI LCD

Specification

Model P/N:PA050XSI
Brand:PVI
Diagonal Size:5.0"
Resolution:320(RGB)×234 79PPI
Contrast Ratio:400 : 1 (Typ.) (TM)
Viewing Angle:70/70/40/60 (Typ.)(CR≥10)
Color Depth:Full color
Backlight:3S5P WLED , 30K hours , No Driver
Signal Type:TFT Specific Analog RGB , 30 pins FPC
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:102.72(W)×74.53(H) mm
Bezel Opening:106.7(W)×78.5(H) mm
Treatment:Antiglare
Luminance:250 cd/m² (Typ.)
Outline(mm):119.3 × 91.4 × 7.8 (H×V×D)
Response:15/30 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:118±5g
Used for:Digital Photo Frame ，Portable DVD Player ，Video Door Phone
Refresh Rate:-
Touchscreen:Without
Voltage Supply:3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VGL)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
