AVIC TM055XYSP02-00 LCD

Specification

Model P/N:TM055XYSP02-00
Brand:AVIC
Diagonal Size:5.5"
Resolution:540(RGB)×960, qHD 201PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Color Depth:16.7M 71% NTSC
Backlight:No B/L
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:68.04(W)×120.96(H) mm
Bezel Opening:-
Treatment:Without Polarizer
Luminance:0 cd/m²
Response:25 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:Normally Black, Transmissive
Mass:-
Used for:Mobile Phone
Refresh Rate:-
Touchscreen:Without
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
Outline (mm):70.84×128.66×0.5 (H×V×D)
Driver IC list:Suggest COG OTM9608A, OTM9605A
Transmissivity:6.12% (Typ.)(with Polarizer)
Glass Thickness:0.25+0.25 mm
