BOE NE156QUM-N67 LCD

Specification

Model P/N:NE156QUM-N67
Brand:BOE
Diagonal Size:15.6"
Resolution:3840(RGB)×2160, UHD 283PPI
Contrast Ratio:1450:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:Oxide TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:344.218(W)×193.622(H) mm
Bezel Opening:-
Outline Dim:350.66(H)×216.12(V) ×2.6(D) mm
Treatment:Antiglare
Luminance:350 cd/m² (Typ.)
View Direction:Symmetry
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:ADS, Normally Black, Transmissive
Support Color:16.7M 99% sRGB
Light Source:WLED [12S6P] , 15K hours , With LED Driver
Designed For:Laptop
Frame Rate:60Hz
Touch Panel:Without
Interface Type:eDP (4 Lanes) , eDP1.4a , HBR2 (5.4G/lane) , 40 pins Connector
Power Supply:3.3V (Typ.)
Form Style:Slim (PCBA Flat, T≤3.2mm)
