AUO A020QL01 V0 LCD

Specification

Model P/N:A020QL01 V0
Brand:AUO
Diagonal Size:2.0"
Resolution:240(RGB)×320, QVGA 199PPI
Contrast Ratio:300:1 (Typ.) (TM)
Viewing Angle:60/60/55/45 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:30.6(W)×40.8(H) mm
Bezel Opening:-
Outline Dim:36.5(H)×50.7(V) ×2.05(D) mm
Treatment:Hard coating
Luminance:255 cd/m² (Typ.)
View Direction:12 o'clock
Response Time:15/20 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K
Light Source:WLED [1S2P] , W/O Driver
Weight:7.70g
Designed For:Mobile Phone
Frame Rate:-
Touch Panel:Without
Interface Type:CPU/RGB/SPI , 40 pins Connector
Power Supply:3.0/3.0V (Max.)(VDD/IOVDD)
