Chimei Innolux N133IGE-L42 LCD

Specification

Model P/N:N133IGE-L42 8
Brand:Chimei Innolux
Diagonal Size:13.3"
Resolution:1280(RGB)×800, WXGA 113PPI
Contrast Ratio:700 : 1 (Typ.) (TM)
Viewing Angle:70/70/55/55 (Typ.)(CR≥10)
Color Depth:262K 72% NTSC
Backlight:WLED , 12K hours , No Driver
Signal Type:LVDS (1 ch, 6-bit) , 30 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:286.08(W)×178.8(H) mm
Bezel Opening:-
Treatment:Glare (Haze 0%), Hard coating (3H)
Luminance:330 cd/m² (Typ.)
Outline(mm):307.44 × 203.2 × 3.75 (H×V×D)
Response:3/7 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Used for:Laptop
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline Shape:Flat (PCBA Flat, T3.4~4.0mm)
