Innolux N140HCN-G53 LCD

Specification

Model P/N:N140HCN-G53
Brand:Innolux
Diagonal Size:14.0"
Resolution:1920(RGB)×1080, FHD 157PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Color Depth:262K 100% sRGB
Backlight:10S5P WLED , 15K hours , With LED Driver
Signal Type:eDP (2 Lanes) , eDP1.3 , Connector 40 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:309.31(W)×173.99(H) mm
Bezel Opening:-
Treatment:Antiglare, Hard coating (3H)
Luminance:300 cd/m² (Typ.)
Response:14/11 (Typ.)(Tr/Td) ms
Good View at:Symmetry
Work Mode:AAS, Normally Black, Transmissive
Used for:Laptop
Refresh Rate:60Hz
Touchscreen:On-Cell Touch, I²C
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):315.81×186.09×5.25 (H×V×D)
Outline Shape:Slim (PCBA Bent, T≤3.0mm)
