Samsung LTN160AT02-H01 LCD

Specification

Model P/N:LTN160AT02-H01
Brand:Samsung
Diagonal Size:16.0"
Resolution:1366(RGB)×768, WXGA 98PPI
Contrast Ratio:600 : 1 (Typ.) (TM)
Viewing Angle:45/45/20/45 (Typ.)(CR≥10)
Color Depth:262K 45% NTSC
Backlight:1 pcs CCFL , 10K hours , No Driver
Signal Type:LVDS (1 ch, 6-bit) , 30 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:353.45(W)×198.72(H) mm
Bezel Opening:356.5(W)×201.8(H) mm
Treatment:Glare (Haze 0%), Hard coating (3H)
Luminance:200 cd/m² (Typ.)
Outline(mm):365 × 214 × 6 (H×V×D)
Response:16 (Typ.)(Tr+Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Used for:Laptop
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline Shape:Wedge (PCBA Bent, T≥5.2mm)
