NLT NL10276BC24-36KD LCD

Specification

Model P/N:NL10276BC24-36KD
Brand:NLT
Diagonal Size:12.1"
Resolution:1024(RGB)×768, XGA 105PPI
Brightness:430 cd/m² (Typ.)
Contrast Ratio:900:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:245.76(W)×184.32(H) mm
Bezel Opening:-
Response Time:3/15 (Typ.)(Tr/Td)
Outline Size:260.5(W)×203(H) ×11.6(D) mm
Surface:Anti Fingerprint + Antiglare, Hard coating (2H)
Best View on:3 o'clock
Display Colors:262K/16.7M 40% NTSC
Lamp Type:4 strings WLED , 70K hours , Without Driver
Frequency:60Hz
Touch Screen:PCAP, Optical Bonding
Panel Weight:730/825g (Typ./Max.)
Application:Industrial
Signal Interface:LVDS (1 ch, 6/8-bit) , 20 pins Connector
Input Voltage:3.3V (Typ.)
