LTN145AT01-H01 Samsung LCD panel replacement

Brand：SAMSUNG
Model：LTN145AT01-H01 (SEC4154)
Diagonal Size：14.5 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：1366(RGB)×768[WXGA]
Configuration：RGB Vertical Stripe
Active Area：321.693(H)×180.864(V) mm
Outline Dim.：336.8(H)×196.9(V)×5.3(D) mm
Bezel Area：324.9(H)×184.1(V) mm
Treatment：Glare (Haze 0%), Hard coating (3H)
Luminance：220 cd/m2 (Typ.)
Contrast Ratio：500:1 (Typ.) (TM)
View Direction：6 o’clock
Response Time：8 (Typ.)(G to G)
Viewing Angle：45/45/15/35 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K 60%(CIE1931)
Light Source：WLED, 12K hours, With LED Driver
Form Style：Wedge (PCBA Bent, Depth ≥5.2mm)
Designed For： Laptop,
Frame Rate： 60Hz
Touch Panel：Without
Interface Type： 40 pinsLVDS (1 ch, 6-bit), Connector
Power Supply：3.3V (Typ.)
Environment：Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C
