QD17TL02 Rev.02 QDI LCD panel replacement

Brand：QDI
Model：QD17TL02 Rev.02 (QDS002F) 1 Compatible
Diagonal Size：17.0 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：1440(RGB)×900[WXGA+]
Configuration：RGB Vertical Stripe
Active Area：367.2(H)×229.5(V) mm
Outline Dim.：382.2(H)×244.5(V)×7(D) mm
Bezel Area：370.6(H)×232.9(V) mm
Treatment：Glare (Haze 0%), Hard coating (3H), Antireflection
Luminance：200 cd/m2 (Typ.)
Contrast Ratio：300:1 (Min.) (TM)
View Direction：6 o’clock
Response Time：10/15 (Typ.)(Tr/Td)
Viewing Angle：65/65/45/55 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K
Light Source：CCFL[1 pcs], 10K hours, W/O Driver
Form Style： Wedge (PCBA Bent, Depth ≥5.2mm)
Designed For： Laptop,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 30 pinsLVDS (2 ch, 6-bit), Connector
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -25 ~ 60 °C
