Samsung LTM184HL01-M01 LCD

Specification

Model P/N:LTM184HL01-M01
Brand:Samsung
Diagonal Size:18.4"
Resolution:1920(RGB)×1080, FHD 119PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Color Depth:262K 72% NTSC
Backlight:12S6P WLED , 15K hours , With LED Driver
Signal Type:LVDS (2 ch, 6-bit) , 40 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:408.96(W)×230.04(H) mm
Bezel Opening:-
Treatment:Antiglare (Haze 25%), Hard coating (3H), Antireflection
Luminance:350 cd/m² (Typ.)
Outline(mm):443.4 × 266.5 × 4.3 (H×V×D)
Response:16 (Typ.)(G to G) ms
Good View at:Symmetry
Work Mode:PLS, Normally Black, Transmissive
Used for:Laptop
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:5.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline Shape:-
