CPT CLAD032JC21 LCD

Specification

Model P/N:CLAD032JC21
Brand:CPT
Diagonal Size:3.2"
Resolution:240(RGB)×400, WQVGA 145PPI
Contrast Ratio:-
Viewing Angle:-
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Empty Cell)
Pixel Format:RGB Vertical Stripe
Active Area:41.76(W)×69.6(H) mm
Bezel Opening:-
Outline Dim:44.9(H)×78.1(V) ×0.6(D) mm
Treatment:Without Polarizer
Luminance:0 cd/m²
View Direction:12 o'clock
Response Time:-
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 69% NTSC
Light Source:No B/L
Weight:-
Designed For:Mobile Phone
Frame Rate:-
Touch Panel:Without
Plate Thickness:0.30+0.30 mm
Transmittance:5.3% (Typ.)(with Polarizer)
D-IC Detail:COG Suggest R61509V, R61517, R61521
