LG Display LM190WX1-TLJ1 LCD

Specification

Model P/N:LM190WX1-TLJ1
Brand:LG Display
Diagonal Size:19.0"
Resolution:1440(RGB)×900, WXGA+ 89PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:85/85/75/85 (Typ.)(CR≥10)
Color Depth:16.7M 71% NTSC
Backlight:4 pcs CCFL , 50K hours , No Driver
Signal Type:LVDS (2 ch, 8-bit) , Connector 30 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:408.24(W)×255.15(H) mm
Bezel Opening:412.24(W)×259.15(H) mm
Treatment:Glare (Haze 0%), Hard coating (2H)
Luminance:300 cd/m² (Typ.)
Response:1.3/3.7 (Typ.)(Tr/Td) ms
Good View at:-
Work Mode:TN, Normally White, Transmissive
Mass:1.72Kgs (Typ.)
Used for:Desktop Monitor
Refresh Rate:75Hz
Touchscreen:Without
Voltage Supply:5.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):428×278×17 (H×V×D)
