LC320WXN-SAB1 LG Display LCD panel replacement

Brand：LG.Philips LCD
Diagonal Size：31.5 inch
Pixel Format：1366(RGB)×768[WXGA]
Active Area：697.685(H)×392.256(V) mm
Bezel Area：703.8(H)×398.4(V) mm
Luminance：500 cd/m2 (Typ.)
View Direction：Symmetry
Viewing Angle：89/89/89/89 (Min.)(CR>10)
Support Color：16.7M 72% (CIE1931)
Weight：6.15/6.77Kgs (Typ./Max.)
Frame Rate： 60Hz
Model：LC320WXN-SAB1
Type：a-Si TFT-LCD , LCM
Configuration：RGB Vertical Stripe
Outline Dim.： 760(H)×450(V)mm
Treatment：Antiglare (Haze 13%), Hard coating (3H)
Contrast Ratio： 1100:1 (Typ.) (TM)
Response Time：8 (Typ.)(G to G)
Operating Mode： S-IPS, Normally Black, Transmissive
Light Source： EEFL [12 pcs] , 50K hours , With Inverter
Designed For： TV Sets,
Touch Panel：Without
Interface Type： 30 pinsLVDS (1 ch, 8-bit), Connector
Power Supply： 12.0V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C
