TIANMA TM043NDH01 LCD

Specification

Model P/N:TM043NDH01
Brand:TIANMA
Diagonal Size:4.3"
Resolution:480(RGB)×272, WQVGA 128PPI
Contrast Ratio:450 : 1 (Typ.) (TM)
Viewing Angle:70/70/70/50 (Typ.)(CR≥10)
Color Depth:16.7M 50% NTSC
Backlight:10S1P WLED , No Driver
Signal Type:Parallel RGB (1 ch, 8-bit) , 45 pins FPC
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:95.04(W)×53.856(H) mm
Bezel Opening:99.2(W)×57.1(H) mm
Treatment:Antiglare
Luminance:350 cd/m² (Typ.)
Outline(mm):105.5 × 67.2 × 4.5 (H×V×D)
Response:20 (Typ.)(Tr+Td) ms
Good View at:12 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:44.5g (Typ.)
Used for:Portable Navigation ，MP3 PMP
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
