LG.Philips LC300W01-A3M2 LCD

Specification

Model P/N:LC300W01-A3M2
Brand:LG.Philips LCD
Diagonal Size:29.5"
Resolution:1280(RGB)×768, WXGA 50PPI
Contrast Ratio:350 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M 69% NTSC
Backlight:16 pcs CCFL , 50K hours , Optional
Signal Type:LVDS (1 ch, 8-bit) , Connector 20 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:643.2(W)×385.92(H) mm
Bezel Opening:649.2(W)×391.8(H) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:450 cd/m² (Typ.)
Response:25 (Typ.)(Tr) ms
Good View at:Symmetry
Work Mode:Normally Black, Transmissive
Mass:6.40Kgs (Typ.)
Used for:TV Sets
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:12.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 50 °C Operating Temp.: 0 ~ 40 °C
Outline (mm):697.8×431.8×15.9 (H×V×D)
