LG.Philips LP150X09-B5K6 LCD

Specification

Model P/N:LP150X09-B5K6
Brand:LG.Philips LCD
Diagonal Size:15.0"
Resolution:1024(RGB)×768, XGA 85PPI
Viewing Angle:-
Color Depth:262K 45% NTSC
Backlight:1 pcs CCFL
Signal Type:LVDS (1 ch, 6-bit)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:304.128(W)×228.096(H) mm
Bezel Opening:-
Response:-
Good View at:-
Work Mode:TN, Normally White, Transmissive
Used for:Laptop
Refresh Rate:60Hz
Touchscreen:-
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline Shape:Wedge (PCBA Bent, T≥5.2mm)
