BOE LC238LF6L LCD

Specification

Model P/N:LC238LF6L
Brand:BOE
Diagonal Size:23.8"
Resolution:1920(RGB)×1080, FHD 92PPI
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , FOB
Pixel Format:RGB Vertical Stripe
Active Area:527.04(W)×296.46(H) mm
Bezel Opening:-
Outline Dim:534.04(H)×307.76(V) ×1.08(D) mm
Treatment:Antiglare (Haze 25%), Hard coating (3H)
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:14 (Typ.)(G to G)
Operating Mode:FFS, Normally Black, Transmissive
Support Color:16.7M 98% sRGB
Light Source:No B/L
Weight:430g (Typ.)
Designed For:Desktop Monitor
Frame Rate:75Hz
Touch Panel:Without
Interface Type:LVDS (2 ch, 8-bit) , 30 pins Connector
Power Supply:5.0V (Typ.)
Plate Thickness:0.40+0.40 mm
Transmittance:5% (Typ.)(with Polarizer)
D-IC Detail:COF Built-in 8 source chips
