AUO B101EAN01.7 CELL LCD

Specification

Model P/N:B101EAN01.7 CELL
Brand:AUO
Diagonal Size:10.1"
Resolution:1280(RGB)×800, WXGA 149PPI
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , FOB
Pixel Format:RGB Vertical Stripe
Active Area:216.96(W)×135.6(H) mm
Bezel Opening:-
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:30 (Typ.)(Tr+Td)
Operating Mode:AHVA, Normally Black, Transmissive
Support Color:16.7M 50% NTSC
Light Source:No B/L
Weight:-
Designed For:Pad & Tablet
Frame Rate:60Hz
Touch Panel:Without
Interface Type:MIPI (4 data lanes) , 34 pins Connector
Power Supply:3.3V (Typ.)
