HYDIS HV070WS1-105 LCD

Specification

Model P/N:HV070WS1-105
Brand:HYDIS
Diagonal Size:7.0"
Resolution:1024(RGB)×600, WSVGA 169PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M 53% NTSC
Backlight:5S4P WLED , 50K hours , No Driver
Signal Type:LVDS (1 ch, 8-bit) + SPI , Connector 30 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:153.6(W)×90(H) mm
Bezel Opening:-
Treatment:-
Luminance:400 cd/m² (Typ.)
Response:50 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:ADS, Normally Black, Transmissive
Mass:95.0g (Max.)
Used for:Pad & Tablet
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -40 ~ 70 °C Operating Temp.: -20 ~ 60 °C
Outline (mm):163.6×102.9×2.67 (H×V×D)
