HITACHI SP14Q002-C2A LCD

Specification

Model P/N:SP14Q002-C2A
Brand:HITACHI
Diagonal Size:5.7"
Resolution:320×240, QVGA 70PPI
Brightness:110 cd/m² (Typ.)
Contrast Ratio:25:1 (Typ.) (TM)
Viewing Angle:40 (Typ.)(CR≥2, Φ2-Φ1)
Panel Type:FSTN-LCD, LCM
Pixel Format:Rectangle
Active Area:115.185(W)×86.385(H) mm
Bezel Opening:-
Response Time:120/150 (Typ.)(Tr/Td)
Outline Size:167(W)×109(H) ×11.4(D) mm
Surface:Glare (Haze 0%)
Best View on:6 o'clock
Display Colors:Monochrome
Lamp Type:1 pcs CCFL , Without Driver
Frequency:75Hz
Touch Screen:4-wire Resistive Touch
Panel Weight:-
Application:Industrial
Signal Interface:Parallel Data (1ch, 4-bit) , 14 pins FPC
Input Voltage:3.3/5.0V (Typ.)(VDD)
