AUO H546UAN01.0 LCD

Specification

Model P/N:H546UAN01.0
Brand:AUO
Diagonal Size:5.5"
Resolution:2160(RG/BR/GB)×3840, UHD 658PPI
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:70/70/70/70 (Typ.)(CR≥100)
Panel Type:LTPS TFT-LCD, LCM
Pixel Format:Rainbow-RGB
Active Area:68.04(W)×120.96(H) mm
Bezel Opening:68.64(W)×121.56(H) mm
Outline Dim:69.84(H)×128.86(V) ×1.38(D) mm
Treatment:-
Luminance:500 cd/m² (Typ.)
View Direction:Symmetry
Response Time:-
Operating Mode:AHVA, Normally Black, Transmissive
Support Color:16.7M 94% NTSC
Light Source:WLED [6S3P] , W/O Driver
Weight:TBD
Designed For:Mobile Phone ，HMD VR AR
Frame Rate:-
Touch Panel:Without
Interface Type:MIPI (2 ch, 4 data lanes) , 60 pins Connector
Power Supply:1.85/1.35V (Typ.)(DVDD/VDDI)
