HITACHI TX09D71VM1CCA LCD

Specification

Model P/N:TX09D71VM1CCA
Brand:HITACHI
Diagonal Size:3.5"
Resolution:240(RGB)×320, QVGA 113PPI
Contrast Ratio:300 : 1 (Typ.) (TM)
Viewing Angle:65/65/80/40 (Typ.)(CR≥5)
Color Depth:262K 49% NTSC
Backlight:6 pcs WLED , With LED Driver
Signal Type:CMOS (1 ch, 6-bit) , 40 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:53.64(W)×71.52(H) mm
Bezel Opening:57.64(W)×75.52(H) mm
Treatment:Hard coating (3H)
Luminance:280 cd/m² (Typ.)
Outline(mm):64 × 86 × 8.35 (H×V×D)
Response:30 (Typ.)(Tr+Td) ms
Good View at:12 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:48.0g (Typ.)
Used for:Handheld & PDA
Refresh Rate:60Hz
Touchscreen:4-wire Resistive Touch
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 70 °C Operating Temp.: -5 ~ 60 °C
