Ortustech COM24H2P39ULC LCD

Specification

Model P/N:COM24H2P39ULC
Brand:Ortustech
Diagonal Size:2.4"
Resolution:240(RGB)×320, QVGA 169PPI
Contrast Ratio:800 : 1 (Typ.) (TM) 2:1 (Typ.) (RF)
Viewing Angle:80/80/80/80 (Min.)(CR≥10)
Color Depth:262K 50% NTSC
Backlight:2S1P WLED , 50K hours , No Driver
Signal Type:CPU , 39 pins FPC
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:36(W)×48(H) mm
Bezel Opening:-
Treatment:Hard coating (2H)
Luminance:300 cd/m² (Typ.)
Outline(mm):42.5 × 58.5 × 5.55 (H×V×D)
Response:60/40 (Max.)(Tr/Td) ms
Good View at:Symmetry
Work Mode:VA, Normally Black, Transflective
Mass:13.6g (Typ.)
Used for:Handheld & PDA
Refresh Rate:-
Touchscreen:Without
Voltage Supply:2.7V (Typ.)(VCI)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
